Mig Welding
MAXI
STEP ADJUSTMENT MIG WELDING EQUIPMENT

SEMI-AUTOMATIC WELDING MACHINES WITH SEPARATE WIRE FEEDER AND ADJUSTMENT BY SWITCH

Three-phase semi-automatic welding equipment, with separate wire feeder, recommended for industrial applications, medium and large fabrication work . MAXI power sources, usable with a wide selection of wire feeders and different length interconnecting cables, are the most complete solution for any job and ensure excellent welding performances on any thickness by granting a very stable arc in any welding position.
MAXI
Other Characteristics
Excellent welding characteristics on any material and with any gas type
Ideal for welding any metal in any industrial application
Control panel protected against accidental impact
Large ergonomic handle for an easy maneuverability
Double inductance connection for a better welding pool in any position
BUY NOW

Datasheet

MAXI: Technical features

TECHNICAL DATA   MAXI 405 MAXI 505
Three phase input 50/60 Hz V 230/400
Input Power @ I2 Max kVA  19  24,2
Delayed Fuse (I2 @ 60%) A 35/20 40/25
Power Factor / cos φ   0,96 0,97
Efficiency Degree   0,77 0,78
Open circuit voltage V 20 – 44 19 – 51
Adjustament positions No. 20 30
Current range A 60 – 400 60 – 500
Duty cycle at (40°C) 100% 230 300
60% 300 370
35% 400 500
20%  –  –
Wires Ø mm 0,6 – 1,6 0,8 – 2,0
Standards   EN 60974-1 • EN 59019
Protection Class IP 23 S
Dimensions (LxWxH) mm 1060 x 600 x 780 1060 x 600 x 780
Weight kg 99 113
Datasheet
